Displays

Element 10         Element 7

Element 7

100% customizable, 7-inch state of the art graphics display, offering crisp and crystal-clear readability in all conditions.

Displays

Element 10         Element 7

Element 7

100% customizable, 7-inch state of the art graphics display, offering crisp and crystal-clear readability in all conditions.

Flexibility

Configure your display with free format values, digits, graphs, and data layouts with our NavDesk app. Allowing you to show as much data as you want. And with our ScreenView app you turn any smart device into a fully functional Sailmon display.

Sailmon Element  G

Visibility

Our Element displays deliver unrivaled viewing in bright sunlight or complete darkness. Perfect sunlight readability is achieved thanks to a high-performance anti-glare front screen. Even high contrast and intense colors are maintained during night sailing.

Adaptability

Our displays are always readable, due to its automatic brightness control, which ensures an instrument experience like no other. Whether you are using them in bright sunlight or pitch black our displays adapt accordingly.

sailmon element  A

Portrait or Landscape

Powerful internal processor allows for intuitive and effective calibration using Computer Assisted Calibration and our 3D calibration methods.

Technical specifications

Dimensions and weight
– See dimensions for Landscape or Portrait orientation

Display:
– LED-Backlit LCD
– 800 X 480 pixels
– 1000cd/m2 max brightness (1000nits max 0,3 min)
– Super wide viewing angle -85 +85 degrees
– Available in Landscape and Portrait orientation

Power:
– Voltage: 10-30V
– Consumption: 10w max, 7w average

Processor:
– A9 dual-core

Interfaces:
– S-net interface can be used to connect the system to any regular network using the Sailethernet box

Environmental requirements:
– Operating ambient temperature: -10 to 50 °C
– IP67 sealed and waterproof

In the box:
– Element 7 Instrument display
– Male and female connectors, including one IP67 dust cap

* Specifications can change without prior notice
** Size and weight vary by configuration and manufacturing process

Element 7

element  portrait

100% customizable, 7-inch state of the art graphics display, offering crisp and crystal-clear readability in all conditions.

Flexibility

Configure your display with free format values, digits, graphs, and data layouts with our NavDesk app. Allowing you to show as much data as you want. And with our ScreenView app you turn any smart device into a fully functional Sailmon display.

Sailmon Element  G

Visibility

Our Element displays deliver unrivaled viewing in bright sunlight or complete darkness. Perfect sunlight readability is achieved thanks to a high-performance anti-glare front screen. Even high contrast and intense colors are maintained during night sailing.

Adaptability

Our displays are always readable, due to its automatic brightness control, which ensures an instrument experience like no other. Whether you are using them in bright sunlight or pitch black our displays adapt accordingly.

sailmon element  A

Portrait or Landscape

Powerful internal processor allows for intuitive and effective calibration using Computer Assisted Calibration and our 3D calibration methods.

Technical specifications

Dimensions and weight
– See dimensions for Landscape or Portrait orientation

Display:
– LED-Backlit LCD
– 800 X 480 pixels
– 1000cd/m2 max brightness (1000nits max 0,3 min)
– Super wide viewing angle -85 +85 degrees
– Available in Landscape and Portrait orientation

Power:
– Voltage: 10-30V
– Consumption: 10w max, 7w average

Processor:
– A9 dual-core

Interfaces:
– S-net interface can be used to connect the system to any regular network using the Sailethernet box

Environmental requirements:
– Operating ambient temperature: -10 to 50 °C
– IP67 sealed and waterproof

In the box:
– Element 7 Instrument display
– Male and female connectors, including one IP67 dust cap

* Specifications can change without prior notice
** Size and weight vary by configuration and manufacturing process
